ADS8344E/2K5
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Analog to Digital Converters (ADC)
Description
20-SSOP (0.154 3.90mm Width) ADS8344 Serial ACTIVE (Last Updated: 5days ago) analog digital converter 1.5mm 1.5mA 100ksps 10mW
PDF
/
Buying Options
Total Price: USD $15.18
Unit Price: USD $15.18
≥1 USD $15.18
≥10 USD $13.948
≥100 USD $13.369664
≥500 USD $11.779768
≥1000 USD $11.20159
≥3000 USD $10.478899
Inventory: 1114
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Thickness 1.5mm
Width 3.9mm
Length 8.65mm
Height 1.75mm
Technical
Spurious-free dynamic range (SFDR) 92 dB
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.25V
Ratio - S/H:ADC 1:1
Conversion Rate 100 ksps
Sample and Hold / Track and Hold SAMPLE
Integral Nonlinearity (INL) 6 LSB
Power Consumption 3.6mW
Output Bit Code BINARY
Sampling Rate (Per Second) 100k
Number of Analog In Channels 8
Voltage - Supply, Digital 2.7V~3.6V 5V
Voltage - Supply, Analog 2.7V~3.6V 5V
Sampling Rate 100 ksps
Resolution 2 B
Data Interface SPI
Reference Type External
Converter Type ADC, SUCCESSIVE APPROXIMATION
Number of Inputs 4, 8
Architecture SAR
Input Type Differential, Single Ended
Number of Bits 16
Power Dissipation 10mW
Nominal Supply Current 1.5mA
Min Supply Voltage 2.7V
Max Supply Voltage 5.25V
Interface Serial
Configuration S/H-ADC
Polarity Unipolar
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 20
Base Part Number ADS8344
Terminal Pitch 0.635mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 10mW
Subcategory Analog to Digital Converters
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
