ADS574JP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Data Acquisition - Analog to Digital Converters (ADC)
Description
Bipolar Unipolar DUAL External Internal SAR Analog to Digital Converter 0C~70C 5.5V 100mW 40ksps
PDF
/
Buying Options
Total Price: USD $24.69
Unit Price: USD $24.6928
≥1 USD $24.6928
Inventory: 1089
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 37.4mm
Height Seated (Max) 6.35mm
Technical
Spurious-free dynamic range (SFDR) 78 dB
Number of Analog Inputs 2
Min Supply Voltage (DC) 4.5V
Differential Nonlinearity 1 LSB
Max Supply Voltage (DC) 5.5V
Negative Supply Voltage-Nom -15V
Signal to Noise Ratio (SNR) 72 dB
Ratio - S/H:ADC 1:1
Conversion Rate 40 ksps
Number of Converters 1
Sample and Hold / Track and Hold SAMPLE
Integral Nonlinearity (INL) 1 LSB
Power Consumption 65mW
Output Bit Code BINARY, OFFSET BINARY
Sampling Rate (Per Second) 40k
Number of Analog In Channels 1
Voltage - Supply, Digital 5V
Voltage - Supply, Analog 5V -16.5V~5.5
Sampling Rate 40 ksps
Resolution 1.5 B
Data Interface Parallel
Reference Type External, Internal
Reference Voltage 2.5V
Supply Type Single
Converter Type ADC, SUCCESSIVE APPROXIMATION
Architecture SAR
Input Type Single Ended
Number of Bits 12
Power Dissipation 100mW
Nominal Supply Current 13mA
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Configuration S/H-ADC
Polarity Bipolar, Unipolar
Operating Supply Voltage 5V
Pin Count 28
Base Part Number ADS574
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 100mW
Subcategory Analog to Digital Converters
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 28
Surface Mount NO
Package / Case 28-DIP (0.600, 15.24mm)
Mounting Type Through Hole
Contact Plating Gold
