ADC0848BCV
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Data Acquisition - Analog to Digital Converters (ADC)
Description
Unipolar J BEND QUAD External Analog to Digital Converter -40C~85C 5V 875mW 25ksps
PDF
/
Buying Options
Total Price: USD $7.83
Unit Price: USD $7.832
≥1 USD $7.832
Inventory: 117
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Number of Pins 28
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Analog to Digital Converters
Max Power Dissipation 875mW
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ADC0848
Pin Count 28
Operating Supply Voltage 5V
Number of Elements 1
Polarity Unipolar
Power Supplies 5V
Configuration MUX-ADC
Max Supply Voltage 6V
Min Supply Voltage 4.5V
Nominal Supply Current 1mA
Power Dissipation 875mW
Number of Bits 8
Input Type Differential, Pseudo-Differential, Single Ended
Architecture SAR
Number of Inputs 4, 8
Converter Type ADC, SUCCESSIVE APPROXIMATION
Supply Type Single
Reference Type External
Data Interface Parallel
Resolution 1 B
Sampling Rate 25 ksps
Voltage - Supply, Analog 4.5V~6V
Voltage - Supply, Digital 4.5V~6V
Number of Analog In Channels 8
Sampling Rate (Per Second) 25k
Output Bit Code BINARY
Power Consumption 15mW
Conversion Rate 25 ksps
Analog Input Voltage-Max 5V
Dimensions
Height Seated (Max) 4.57mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
