MAX165ACWN
RoHS
/
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Analog to Digital Converters (ADC)
Description
18-SOIC (0.295 7.50mm Width) MAX165 Tube ADC SUCCESSIVE APPROXIMATION analog digital converter 2.65mm 6mA 0.2MHz 2000
PDF
/
Buying Options
Total Price: USD $96.7
Unit Price: USD $96.69765
≥1 USD $96.69765
≥10 USD $93.5788
≥100 USD $90.45995
≥500 USD $81.1015
Inventory: 1172
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2000
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Subcategory Analog to Digital Converters
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX165
Pin Count 18
Qualification Status Not Qualified
Power Supplies 5V
Configuration S/H-ADC
Number of Bits 8
Supply Current-Max 6mA
Input Type Single Ended
Architecture SAR
Number of Inputs 1
Converter Type ADC, SUCCESSIVE APPROXIMATION
Reference Type External, Internal
Data Interface Parallel
Sampling Rate 0.2 MHz
Voltage - Supply, Analog 5V
Number of Analog In Channels 1
Sampling Rate (Per Second) 200k
Output Bit Code BINARY, OFFSET BINARY
Sample and Hold / Track and Hold TRACK
Ratio - S/H:ADC 1:1
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
