VSP2566PTRG4
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Data Acquisition - Analog Front End (AFE)
Description
QUAD Obsolete Surface Mount OTHER AFE 2B 7mm 86mW 85C
PDF
/
Inventory: 7682
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
Consumer IC Type CONSUMER CIRCUIT
Conversion Rate 36 Msps
Number of Converters 1
Voltage - Supply, Digital 2.7V~3.6V
Voltage - Supply, Analog 2.7V~3.6V
Sampling Rate 36 Msps
Resolution 2 B
Number of Bits 16
Min Supply Voltage 2.7V
Max Supply Voltage 3.6V
Interface Serial
Number of Channels 2
Temperature Grade OTHER
Operating Supply Voltage 3V
Pin Count 48
Base Part Number VSP2566
Terminal Pitch 0.5mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position QUAD
Max Power Dissipation 86mW
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tape & Reel (TR)
Physical
Weight 181.692094mg
Number of Pins 48
Package / Case 48-LQFP
Mount Surface Mount
