VSP2562PTG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 48-LQFP
Category Integrated Circuits (ICs) / Data Acquisition - Analog Front End (AFE)
Description VSP2562 48-LQFP Serial GULL WING analog front end circuit 2.7V~3.6V 36Msps 85C 86mW
PDF
/
Inventory: 4151
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 7mm
Length 7mm
Height 1.4mm

Technical

Consumer IC Type CONSUMER CIRCUIT
Number of Converters 1
Voltage - Supply, Digital 2.7V~3.6V
Voltage - Supply, Analog 2.7V~3.6V
Sampling Rate 36 Msps
Resolution 1.5 B
Number of Bits 12
Min Supply Voltage 2.7V
Max Supply Voltage 3.6V
Interface Serial
Number of Channels 2
Temperature Grade OTHER
Operating Supply Voltage 3V
Pin Count 48
Base Part Number VSP2562
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Max Power Dissipation 86mW
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e4
Packaging Tray

Physical

Weight 181.692094mg
Number of Pins 48
Package / Case 48-LQFP
Mount Surface Mount
