ADS1298IPAG
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Data Acquisition - Analog Front End (AFE)
Description
ADS1298 64-TQFP SPI ACTIVE (Last Updated: 3days ago) analog front end ic 1.65V~3.6V 32ksps 85C 8.8mW
PDF
/
Buying Options
Total Price: USD $22.82
Unit Price: USD $22.8209
≥1 USD $22.8209
≥10 USD $18.72545
≥100 USD $18.14025
≥500 USD $17.55505
≥1000 USD $16.96985
≥3000 USD $15.21425
Inventory: 6802
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Package / Case 64-TQFP
Surface Mount YES
Number of Pins 64
Technical
Packaging Tray
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
ECCN Code EAR99
Type General Purpose
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Power (Watts) 14.1mW
Additional Feature IT ALSO REQUIRES DIGITAL SUPPLY OF 1.65V TO 3.6V
Max Power Dissipation 8.8mW
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Base Part Number ADS1298
Pin Count 64
Temperature Grade INDUSTRIAL
Number of Channels 8
Interface SPI
Max Supply Voltage 5.25V
Min Supply Voltage 2.7V
Operating Supply Current 3.1mA
Number of Bits 24
Resolution 3 B
Sampling Rate 32 ksps
Voltage - Supply, Analog 2.7V~5.5V
Voltage - Supply, Digital 1.65V~3.6V
Power Consumption 6mW
Number of Converters 8
Conversion Rate 32 ksps
Signal to Noise Ratio (SNR) 112 dB
Max Supply Voltage (DC) 3.6V
Min Supply Voltage (DC) 1.65V
Dimensions
Height 1.2mm
Length 10mm
Width 10mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
