MCP3901A0-E/SS

Microchip Technology
RoHS
RoHS RoHS compliant
Package 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Analog Front End (AFE)
Description MCP3901 20-SSOP (0.209 5.30mm Width) SPI Serial ANALOG CIRCUIT analog front end circuit 2.7V~5.5V 64ksps 125C 1.85mm
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.39387
≥1 USD $0.39387
≥200 USD $0.152428
≥500 USD $0.147071
≥1000 USD $0.144419
Inventory: 1548
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20

Technical

Packaging Tube
Published 2010
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP3901
Pin Count 20
Temperature Grade INDUSTRIAL
Interface SPI, Serial
Max Supply Voltage 5.5V
Min Supply Voltage 2.7V
Analog IC - Other Type ANALOG CIRCUIT
Number of Bits 24
Resolution 2 B
Sampling Rate 64 ksps
Voltage - Supply, Analog 5V
Voltage - Supply, Digital 2.7V~5.5V
Number of Converters 2
Conversion Rate 64 ksps
Signal to Noise Ratio (SNR) 91 dB

Dimensions

Height 1.85mm
Length 7.5mm
Width 5.6mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
