PCM1717EG
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DAC 18BIT STEREO AUDIO 20SSOP
PDF
/
Buying Options
Total Price: USD $7.44
Unit Price: USD $7.442931
≥1 USD $7.442931
≥10 USD $7.021635
≥100 USD $6.624185
≥500 USD $6.249227
≥1000 USD $5.895496
Inventory: 1091
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Weight 160.004709mg
Technical
Operating Temperature -25°C~85°C
Packaging Tube
Series SoundPlus?
JESD-609 Code e6
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type DAC, Audio
Terminal Finish Tin/Bismuth (Sn/Bi)
Subcategory Other Converters
Max Power Dissipation 125mW
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number PCM1717
Pin Count 20
Output Type Voltage
Operating Supply Voltage 5.5V
Power Supplies 5V
Number of Channels 3
Interface Serial
Nominal Supply Current 18mA
Number of Bits 18
Supply Type Analog, Digital
Data Interface I2S
Sampling Rate 48 ksps
Settling Time 0.0104 μs
Sampling Rate (Per Second) 48k
Conversion Rate 48 ksps
Voltage Supply Source Analog Digital
Signal to Noise Ratio (SNR) 100 dB
Resolution (Bits) 18 b
Number of DAC Channels 2
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
