MSC1201Y2RHHT
RoHS
RoHS compliant
RoHS compliantPackage 36-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC 8051 CPU PREC ADC/DAC 36-VQFN
PDF
/
Buying Options
Total Price: USD $16.11
Unit Price: USD $16.10915
≥1 USD $16.10915
≥10 USD $13.2183
≥100 USD $12.80505
≥500 USD $12.3918
≥1000 USD $11.97855
Inventory: 1005
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 1mm
Technical
Voltage Supply Source Analog Digital
Number of Programmable I/O 16
Power Consumption 4mW
Sampling Rate (Per Second) 1k
Core Architecture 8051
Sampling Rate 1 ksps
Number of Timers/Counters 2
Data Interface SPI
Supply Type Analog, Digital
DAC Channels YES
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Bit Size 8
Number of Bits 24
Memory Type FLASH
RAM Size 256B
Nominal Supply Current 33mA
Number of I/O 16
Memory Size 4kB
Interface I2C, SPI, Serial, USART
Number of Channels 6
Power Supplies 3/5V
Pin Count 36
Base Part Number MSC1201Y2
Frequency 33MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Terminal Position QUAD
Voltage - Supply 2.7V~5.25V
Technology CMOS
Subcategory Microcontrollers
Type ADC and DAC: MCU Based
Number of Terminations 36
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 36
Package / Case 36-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
