LM12458CIV
RoHS
/
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DAS 12BIT 140K 44PLCC
PDF
/
Buying Options
Total Price: USD $22.12
Unit Price: USD $22.1198
≥1 USD $22.1198
≥10 USD $18.14975
≥100 USD $17.5826
≥500 USD $17.01545
≥1000 USD $16.4483
Inventory: 1197
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 16.51mm
Length 16.51mm
Height 3.68mm
Technical
Resolution (Bits) 12 b
Differential Nonlinearity 0.75 LSB
Signal to Noise Ratio (SNR) 77.5 dB
Voltage Supply Source Analog Digital
Conversion Rate 114 ksps
Integral Nonlinearity (INL) 1 LSB
Power Consumption 30mW
Sampling Rate (Per Second) 140k
Sampling Rate 114 ksps
Data Interface Parallel
Supply Type Analog, Digital
Number of Bits 12
Number of Channels 8
Supply Voltage-Min (Vsup) 3V
Polarity Bipolar
Number of Elements 1
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 44
Base Part Number LM12458
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 3V~5.5V
Terminal Finish Tin/Lead (Sn/Pb)
Type Data Acquisition System (DAS)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 44
Package / Case 44-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
