AMC1204BDWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DELTA SIGMA MOD 16BIT 16-SOIC
PDF
/
Buying Options
Total Price: USD $6.03
Unit Price: USD $6.028
≥1 USD $6.028
≥10 USD $5.44632
≥100 USD $5.192704
≥500 USD $4.508856
≥1000 USD $4.306227
≥3000 USD $3.926278
Inventory: 1628
Minimum: 1
-
+
Technical Details
Dimensions
Width 7.5mm
Thickness 2.35mm
Length 10.3mm
Height 2.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Technical
Number of Analog Inputs 1
Resolution (Bits) 16 b
Analog Input Voltage-Min -0.25V
Differential Nonlinearity 1 LSB
Signal to Noise Ratio (SNR) 88 dB
Voltage Supply Source Analog Digital
Analog Input Voltage-Max 0.32V
Conversion Rate 78 ksps
Integral Nonlinearity (INL) 16 LSB
Linearity Error-Max (EL) 800%
Power Consumption 88mW
Output Bit Code BINARY
Sampling Rate (Per Second) 78k
Number of Analog In Channels 1
Sampling Rate 78 ksps
Data Interface SPI
Supply Type Analog, Digital, Single
Supply Current-Max 5mA
Number of Bits 1
Power Dissipation 61.6mW
Interface Serial
Polarity Bipolar
Pin Count 16
Base Part Number AMC1204
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.3V 5V
Max Power Dissipation 102.4mW
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Modulator
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
