MAX192BCWP
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DAS 10BIT 133K 20SOIC
PDF
/
Buying Options
Total Price: USD $15.86
Unit Price: USD $15.8576
≥1 USD $15.8576
Inventory: 973
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Resolution (Bits) 10 b
Conversion Time-Max 2μs
Voltage Supply Source Single Supply
Sample and Hold / Track and Hold TRACK
Output Bit Code BINARY, 2'S COMPLEMENT BINARY
Sampling Rate (Per Second) 133k
Number of Analog In Channels 8
Sampling Rate 0.133 MHz
Data Interface Serial
Number of Bits 10
Number of Channels 8
Power Supplies 5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G20
Pin Count 20
Base Part Number MAX192
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Analog to Digital Converters
Type Data Acquisition
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 1998
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
