MAX186DCPP
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DAS 12BIT 133K 20DIP
PDF
/
Buying Options
Total Price: USD $24.88
Unit Price: USD $24.8843
≥1 USD $24.8843
≥10 USD $20.41835
≥100 USD $19.77995
≥500 USD $19.1425
≥1000 USD $18.5041
Inventory: 1184
Minimum: 1
-
+
Technical Details
Technical
Number of Terminations 20
ECCN Code EAR99
Type Data Acquisition
Subcategory Analog to Digital Converters
Technology CMOS
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX186
Pin Count 20
JESD-30 Code R-PDIP-T20
Qualification Status Not Qualified
Power Supplies 5/+-5V
Number of Channels 8
Number of Bits 12
Supply Current-Max 2.5mA
Data Interface Serial
Sampling Rate 0.133 MHz
Number of Analog In Channels 8
Sampling Rate (Per Second) 133k
Output Bit Code BINARY, 2'S COMPLEMENT BINARY
Linearity Error-Max (EL) 0.0244%
Sample and Hold / Track and Hold TRACK
Voltage Supply Source Dual ±
Negative Supply Voltage-Nom -5V
Conversion Time-Max 10μs
Resolution (Bits) 12 b
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 1996
Packaging Tube
Operating Temperature 0°C~70°C
Dimensions
Height Seated (Max) 4.572mm
Length 26.16mm
Width 7.62mm
Physical
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
