MAX186ACPP+
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DAS/ADC 12BIT 133K 20DIP
PDF
/
Buying Options
Total Price: USD $58.09
Unit Price: USD $58.0888
≥1 USD $58.0888
≥10 USD $54.56792
≥100 USD $52.80792
≥500 USD $48.93548
Inventory: 98
Minimum: 1
-
+
Technical Details
Technical
Output Bit Code BINARY, 2'S COMPLEMENT BINARY
Sampling Rate (Per Second) 133k
Number of Analog In Channels 8
Sampling Rate 133 ksps
Data Interface MICROWIRE?, QSPI?, Serial, SPI?
Supply Type Dual
Number of Bits 12
Nominal Supply Current 1.5mA
Interface SPI, Serial
Number of Channels 8
Polarity Bipolar, Unipolar
Operating Supply Voltage 5V
Pin Count 20
Base Part Number MAX186
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Voltage - Supply ±5V
Technology CMOS
Max Power Dissipation 889mW
Subcategory Analog to Digital Converters
Terminal Finish Matte Tin (Sn)
Type Data Acquisition System (DAS), ADC
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Tube
Operating Temperature 0°C~70°C
Resolution (Bits) 12 b
Negative Supply Voltage-Nom -5V
Voltage Supply Source Dual ±
Conversion Rate 133 ksps
Dual Supply Voltage 5V
Number of A/D Converters 1
Sample and Hold / Track and Hold TRACK
Integral Nonlinearity (INL) 0.5 LSB
Physical
Number of Pins 20
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.87mm
Length 26.54mm
Height 4.45mm
