MAX127BCAI+
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
Data Acquisition ADCs/DACs - Specialized 12-Bit 8Ch 8ksps 4.18V Precision ADC
PDF
/
Buying Options
Total Price: USD $32.57
Unit Price: USD $32.5688
≥1 USD $32.5688
≥10 USD $30.38376
≥100 USD $29.110022
≥500 USD $26.38093
≥1000 USD $25.471222
Inventory: 157
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.29mm
Length 10.2mm
Height Seated (Max) 1.99mm
Technical
Resolution (Bits) 12 b
Voltage Supply Source Single Supply
Sampling Rate (Per Second) 8k
Data Interface I2C, Serial
Number of Bits 12
Number of Channels 8
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status Not Qualified
Pin Count 28
Base Part Number MAX127
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Terminal Finish TIN
Type Data Acquisition System (DAS), ADC
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1998
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
