ICL7136CPL+3

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description IC DISPLAY DRIVR 3.5DIGIT 40DIP
PDF
/
Inventory: 2700
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length 52.07mm
Height Seated (Max) 5.08mm

Technical

Resolution (Bits) 3.5 Digit
Voltage Supply Source Single Supply
Output Format PARALLEL, WORD
Analog Input Voltage-Max 2V
Output Bit Code BINARY
Number of Analog In Channels 1
Number of Bits 16
Number of Channels 1
Power Supplies 9V
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T40
Pin Count 40
Base Part Number ICL7136
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 9V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 9V
Technology CMOS
Subcategory Analog to Digital Converters
Terminal Finish Matte Tin (Sn)
Type Display Driver
ECCN Code EAR99
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 1999
Packaging Tube
Operating Temperature 0°C~70°C

Physical

Surface Mount NO
Package / Case 40-DIP (0.600, 15.24mm)
Mounting Type Through Hole
