LTC1294BCSW#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
IC DAS/ADC 12BIT 46.5K 20SOIC
PDF
/
Buying Options
Total Price: USD $38.21
Unit Price: USD $38.206703
≥1 USD $38.206703
≥200 USD $14.78588
≥500 USD $14.265971
≥1000 USD $14.009956
Inventory: 1146
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.493mm
Length 13.3mm
Height Seated (Max) 2.95mm
Technical
Resolution (Bits) 12 b
Negative Supply Voltage-Nom -5V
Voltage Supply Source Dual ±
Analog Input Voltage-Max 5V
Sample and Hold / Track and Hold SAMPLE
Linearity Error-Max (EL) 0.0122%
Output Bit Code BINARY
Sampling Rate (Per Second) 46.5k
Number of Analog In Channels 8
Sampling Rate 0.0465 MHz
Data Interface Serial, Parallel
Number of Bits 12
Number of Channels 8
Power Supplies 5/+-5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G20
Pin Count 20
Base Part Number LTC1294
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 250
Terminal Form GULL WING
Voltage - Supply ±5V 5V
Technology CMOS
Subcategory Analog to Digital Converters
Terminal Finish Matte Tin (Sn)
Type Data Acquisition System (DAS), ADC
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
