LTC1293CCJ
RoHS
/
Package 20-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Data Acquisition - ADCs/DACs - Special Purpose
Description
12-BIT SERIAL I/O ADC W/6 CH MUX
PDF
/
Inventory: 1447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 19.05mm
Technical
Resolution (Bits) 12 b
Analog Input Voltage-Min -6.3V
Voltage Supply Source Dual ±
Output Format PARALLEL, WORD
Analog Input Voltage-Max 12.3V
Linearity Error-Max (EL) 0.012%
Output Bit Code OFFSET BINARY
Sampling Rate (Per Second) 46.5k
Sampling Rate 0.077 MHz
Data Interface Serial, Parallel
Number of Bits 12
Number of Channels 8
Qualification Status Not Qualified
JESD-30 Code R-GDIP-T16
Pin Count 16
Base Part Number LTC1293
Terminal Pitch 2.54mm
Number of Functions 1
Voltage - Supply ±5V
Terminal Finish Tin/Lead (Sn/Pb)
Type Data Acquisition System (DAS), ADC
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 20-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
Alternative Model
