EHDB9FFB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description
D-Sub Adapters & Gender Changers EH SERIES DB9 FEM-FE
PDF
/
Buying Options
Total Price: USD $14.15
Unit Price: USD $14.1504
≥1 USD $14.1504
≥10 USD $12.26368
≥100 USD $11.623744
≥500 USD $11.455312
≥1000 USD $10.398696
Inventory: 135
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 26mm
Length 31mm
Technical
Number of ContactsSide 2 9
Number of ContactsSide 1 9
Straight Connection YES
Convert To (Adapter End) D-Sub, 9 Pin Female
Convert From (Adapter End) D-Sub, 9 Pin Female
Includes 5 pcs - 1 Connector, 1 Flange, 1 Housing, 2 Screws
Number of Ports 1
Connector Style Gender Changer
Empty Shell NO
Housing Color Yellow
Contact Finish Gold
Current Rating 1.5A
Depth 18.4mm
Orientation Straight
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female to Female
Number of Rows 2
Color Black
Min Operating Temperature -10°C
Max Operating Temperature 60°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series EH
Published 2008
Physical
Shell Material, Finish Nickel Silver, Black Chrome Plated
Number of Pins 9
Mounting Type Panel Mount, Square Flange
Mount Flanges, Panel
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
