243A13780X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description
TIN 243A ROHS3Compliant COMMERCIAL Connector Adapter 50Cycles 3.336N 10mOhm -25C~85C
PDF
/
Inventory: 7545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness Flash
Technical
Convert To (Adapter End) D-Sub, 15 Pin Female
Convert From (Adapter End) D-Sub, 15 Pin Male
Contact Design PREASSEM CONN
Includes 3 pcs - 1 Connector, 2 Jack Screws
Withdrawl Force-Min 3.336 N
Insertion Force-Max 3.336 N
Contact Pattern STAGGERED
Durability 50 Cycles
Connector Style Connector Saver
Dielectric Withstanding Voltage 300VDC V
Termination Type SOLDER LUG
Body/Shell Style PLUG
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Housing Color Black
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Shell Finish TIN
Ingress Protection IP20
Total Number of Contacts 15
Current Rating (Amps) 3A
Filter Feature YES
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature ROHS COMPLIANT
Voltage - Rated 100V
Number of Rows 2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Filter
Series 243A
Published 2015
Operating Temperature -25°C~85°C
Physical
Mounting Option 2 JACKSCREW
Shell Material, Finish Steel, Tin Plated
Mounting Option 1 #4-40
Insulation Material GLASS FILLED POLYESTER
Number of Pins 15
Mounting Type Free Hanging (In-Line)
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
