243A13260X

Conec
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description D-Sub Adapter Connector
PDF
/
Inventory: 3328
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 8.00μin 0.203μm

Technical

Number of ContactsSide 2 25
Number of ContactsSide 1 25
Straight Connection YES
Convert To (Adapter End) D-Sub, 25 Pin Female
Convert From (Adapter End) D-Sub, 25 Pin Male
Includes 3 pcs - 1 Connector, 2 Jack Screws
Connector Style Connector Saver
Body/Shell Style SOCKET-PLUG
Empty Shell NO
Housing Color Silver
Contact Gender FEMALE-MALE
Contact Finish Gold
Ingress Protection IP20
Current Rating (Amps) 7.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 100V
Number of Rows 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Filter
JESD-609 Code e3
Series 243A
Published 2006
Operating Temperature -25°C~105°C

Physical

Shell Material, Finish Steel, Tin Plated
Number of Pins 25
Mounting Type Free Hanging (In-Line)
Contact Material COPPER ALLOY

Supply Chain

Factory Lead Time 12 Weeks
