243A12470X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description
243A ROHS3Compliant GENERAL PURPOSE IP20 Connector Adapter -25C~105C 7.5A 100V Flash
PDF
/
Inventory: 9078
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness Flash
Technical
Number of ContactsSide 2 37
Number of ContactsSide 1 37
Straight Connection YES
Convert To (Adapter End) D-Sub, 37 Pin Female
Convert From (Adapter End) D-Sub, 37 Pin Male
Includes 3 pcs - 1 Connector, 2 Jack Screws
Connector Style Connector Saver
Body/Shell Style SOCKET-PLUG
Empty Shell NO
Housing Color Silver
Contact Gender FEMALE-MALE
Contact Finish Gold
Ingress Protection IP20
Current Rating (Amps) 7.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 100V
Number of Rows 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Filter
JESD-609 Code e3
Series 243A
Operating Temperature -25°C~105°C
Physical
Shell Material, Finish Steel, Tin Plated
Number of Pins 37
Mounting Type Free Hanging (In-Line)
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
