243A10090X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description
CONN DSUB ADAPTER DB9F DB9M
PDF
/
Inventory: 4501
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 8.00μin 0.203μm
Technical
Gender Type B Female
Gender Type A Male
Convert To (Adapter End) D-Sub, 9 Pin Female
Convert From (Adapter End) D-Sub, 9 Pin Male
Includes 3 pcs - 1 Connector, 2 Jack Screws
Insertion Force-Max 3.336 N
Contact Pattern STAGGERED
Connector Style Connector Saver
Body/Shell Style PLUG/RECEPTACLE
Insulation Resistance 100000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Housing Color Black
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish TIN OVER NICKEL
Ingress Protection IP20
Total Number of Contacts 9
Current Rating (Amps) 7.5A
Filter Feature YES
Subcategory D Type Connectors
Additional Feature ADAPTER
Voltage - Rated 100V
Number of Rows 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Filter
Series 243A
Published 2001
Operating Temperature -25°C~105°C
Physical
Shell Material, Finish Steel, Tin Plated
Insulation Material GLASS FILLED POLYESTER
Number of Pins 9
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
