RoHS
/
Package /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description D-Sub Adapter Connector
PDF
/
Buying Options
Total Price: USD $120.39
Unit Price: USD $120.393593
≥1 USD $120.393593
≥10 USD $113.578861
≥100 USD $107.149867
≥500 USD $101.084783
≥1000 USD $95.363009
Inventory: 935
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Number of ContactsSide 2 37
Number of ContactsSide 1 37
Straight Connection YES
Convert To (Adapter End) D-Sub, 37 Pin Female
Convert From (Adapter End) D-Sub, 37 Pin Male
Connector Style Connector Saver
Body/Shell Style PLUG-RECEPTACLE
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender MALE-FEMALE
Contact Finish Gold
Current Rating (Amps) 5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.80.00
Voltage - Rated 100V
Number of Rows 2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Filter
Series 700
Published 2014
Operating Temperature -55°C~125°C

Physical

Shell Material, Finish Nickel Plated
Mounting Type Free Hanging (In-Line)
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 10 Weeks
