56-705-008
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description
D-Shaped Adapter Connector
PDF
/
Inventory: 3753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Number of ContactsSide 2 9
Number of ContactsSide 1 9
Straight Connection YES
Gender Type B Female
Gender Type A Male
Convert To (Adapter End) D-Sub, 9 Pin Female
Convert From (Adapter End) D-Sub, 9 Pin Male
Connector Type B D-Sub, Standard
Connector Type A D-Sub, Standard
Connector Style Connector Saver
Plating Nickel
Body/Shell Style PLUG-RECEPTACLE
Empty Shell NO
UL Flammability Code 94V-0
Contact Finish Gold
Current Rating 5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Capacitance 50pF
HTS Code 8536.69.80.00
Voltage - Rated 200V
Number of Rows 2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Filter
Series 700
Published 2014
Operating Temperature -55°C~125°C
Physical
Shell Material, Finish Nickel Plated
Shell Material Zinc
Number of Pins 1
Mounting Type Free Hanging (In-Line)
Contact Material NOT SPECIFIED
