6-175710-2
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-TYPE PLUG 40P VERT KINKED
PDF
/
Inventory: 5075
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Contacts 40
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Lead Length 3.1mm
Empty Shell NO
Body Depth 0.106 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Body/Shell Style PLUG
ELV Compliant
Dielectric Withstanding Voltage 500VAC V
PCB Contact Row Spacing 1.905 mm
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Number Of PCB Rows 4
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 1A
Shielding Unshielded
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
Additional Feature AMPLIMITE
Voltage - Rated 100V
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Pbfree Code no
JESD-609 Code e0
Dimensions
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Physical
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
