RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub Connector
PDF
/
Inventory: 6311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

PCB Thickness 1.1938mm
Length 31.19mm

Technical

Mating Connector Lock With
Preloaded Yes
Circuit Application Signal
Sealable No
Plating Tin
ELV Compliant
Lead Length 2.1336mm
Number of Contacts 9
Row Spacing - Mating 2.8448 mm
Current Rating 3A
Orientation Right Angle
Pitch 2.7432mm
Voltage - Rated 250V
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 9
Connector Type Plug
Termination Solder

Physical

PCB Mount Retention With
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Shell Material Steel
Contact Shape Round
Mount Through Hole
Contact Plating Tin

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 months ago)
