RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub MIL Spec Connectors ASM RCPT POSTED109 5
PDF
/
Inventory: 4378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Contact Material Brass
Contact Plating Gold
Mount Through Hole
Shell Material Steel
Housing Material Polyester
PCB Mounting Orientation Vertical

Technical

Packaging Bulk
Pbfree Code no
Number of Terminations 50
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Rows 2
Gender Female
HTS Code 8536.69.40.30
Subcategory D Type Connectors
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.77mm
Total Number of Contacts 50
Depth 15.37mm
Current Rating 5A
Reliability COMMERCIAL
Number Of PCB Rows 3
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Housing Color Black
Lead Length 4.78mm
Empty Shell NO
Contact Style RND PIN-SKT
ELV Non-Compliant
Shell Size 5/D
Plating Cadmium
Number of Ports 1
PCB Contact Row Spacing 5.6896 mm
Contact Pattern STAGGERED
Sealable No
Circuit Application Signal
Hole Diameter 3.05 mm

Dimensions

Height 12.3mm
Length 66.93mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
