204539-2
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
STANDARD: MIL-DTL-24308 D-Sub Connector
PDF
/
Inventory: 5460
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Bushing
Housing Material Steel
Technical
Number of Terminations 26
ECCN Code EAR99
Connector Type Pin, Plug
Number of Rows 3
Gender Male
Additional Feature STANDARD: MIL-DTL-24308
HTS Code 8536.69.40.30
Subcategory D Type Connectors
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 26
Orientation Straight
Reliability COMMERCIAL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.509 inch
Empty Shell NO
Contact Style Crimp
ELV Non-Compliant
Shell Size 2/A
Plating Cadmium
Number of Ports 1
Contact Pattern STAGGERED
Hole Diameter 3.05 mm
Contact Design PREASSEM CONN
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Not Applicable
