2-174726-4
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Standard Connectors AMLPIMITE 050 PLUG 50P TYPE A
PDF
/
Inventory: 5367
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Shell Material Zinc
Housing Material Thermoplastic
PCB Mounting Orientation Right Angle
Technical
JESD-609 Code e0
Feature Shielded
Pbfree Code no
Termination Solder
Connector Type Receptacle
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Voltage - Rated 100V
Subcategory Other Rectangular Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Orientation Right Angle
Current Rating 1A
Reference Standard UL
Reliability COMMERCIAL
Number of Contacts 50
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.406 inch
Contact Gender MALE
Lead Length 3.4mm
Empty Shell NO
Body Depth 0.461 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 30mOhm
Insulation Resistance 1000000000Ohm
Body/Shell Style PLUG
ELV Compliant
Plating Copper, Nickel
Dielectric Withstanding Voltage 700VAC V
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Contact Design PREASSEM CONN
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
