1757839-5
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
AMPLIMITE,PLUG ASY,R/A,109,ZN,5
PDF
/
Inventory: 6235
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.168 inch
Technical
Circuit Application Signal
Sealable No
Contact Pattern STAGGERED
PCB Contact Row Spacing 2.8448 mm
Plating Zinc
Shell Size 5/D
ELV Compliant
Contact Style RND PIN-SKT
Body Depth 0.604 inch
Empty Shell NO
Lead Length 4.78mm
Body Breadth 0.62 inch
PCB Contact Pattern STAGGERED
Number of Contacts 50
Number Of PCB Rows 3
Body Length or Diameter 2.65 inch
Reliability COMMERCIAL
Current Rating 5A
Orientation Right Angle
Pitch 2.77mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory D Type Connectors
Additional Feature STANDARDS: MIL-C-24308; MIL-C-39029, AMPLIMITE
Gender Male
Number of Rows 3
Connector Type Pin, Plug
Termination Solder
Packaging Bulk
Physical
PCB Mounting Orientation Right Angle
Shell Material Steel
Mount Through Hole
Contact Plating Gold
Contact Material Brass, Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
