174684-6
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Standard Connectors AMPLIMITE 050 CAP H 48P
PDF
/
Inventory: 9275
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 8μin
Technical
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 1.905 mm
Dielectric Withstanding Voltage 500VAC V
ELV Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Empty Shell NO
Lead Length 3.6mm
UL Flammability Code 94V-0
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern STAGGERED
Number of Contacts 48
Number Of PCB Rows 4
Body Length or Diameter 1.59 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 1A
Shielding Unshielded
Orientation Right Angle
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature AMPLIMITE
Voltage - Rated 100V
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Plug
ECCN Code EAR99
Termination Solder
Pbfree Code no
JESD-609 Code e0
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
