174207-8
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
AMPLIMITE D-Sub Connector
PDF
/
Inventory: 5758
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Mount Through Hole
Shell Material POLYBUTYLENE TEREPHTHALATE
Housing Material PBT
Technical
Termination Solder
ECCN Code EAR99
Connector Type Plug, Signal
Number of Positions 96
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Voltage - Rated 100V
Additional Feature AMPLIMITE
HTS Code 8536.69.40.30
Subcategory D Type Connectors
Contact Finish - Mating AU ON NI
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 96
Reach Compliance Code unknown
Current Rating 1A
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.479 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 50mOhm
Insulation Resistance 500000000Ohm
Mating Contact Pitch 0.05 inch
Body/Shell Style RECEPTACLE
PCB Contact Row Spacing 1.905 mm
Contact Pattern RECTANGULAR
Insertion Force-Max .7784 N
Withdrawl Force-Min .1946 N
Mating Contact Row Spacing 0.1 inch
Dimensions
Plating Thickness 30μin
Compliance
RoHS Status RoHS Compliant
