1218126-5
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub MIL Spec Connectors 50 POS ASSM PLUG LOW PROF 109
PDF
/
Inventory: 7744
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Termination Solder
ECCN Code EAR99
Connector Type Pin, Plug
Number of Rows 2
Gender Male
HTS Code 8536.69.40.30
Subcategory D Type Connectors
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 50
Depth 15.75mm
Reliability COMMERCIAL
Number Of PCB Rows 3
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Housing Color Black
Lead Length 3.95mm
Empty Shell NO
Contact Style RND PIN-SKT
ELV Non-Compliant
Shell Size 5/D
Plating Cadmium
Number of Ports 1
Contact Pattern STAGGERED
Hole Diameter 3.05 mm
Number of Terminations 50
Pbfree Code no
Packaging Bulk
Dimensions
Length 67.31mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
Physical
PCB Mounting Orientation Vertical
Housing Material Polyester
Shell Material Steel
Mount Through Hole
Contact Plating Gold
Contact Material Brass
