1655360
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Mixed Contact Connectors VS-15-ST-DSUB- 2P-5S-LH
PDF
/
Inventory: 1120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Insulation Insulated
Shell Size, Connector Layout 2 DA A - 7W2
Connector Style D-Sub, Combo
Flange Feature Housing/Shell (4-40)
Empty Shell NO
UL Flammability Code 94V-0
Contact Finish Gold
Current Rating 5A
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Signal and Coax or Power (Not Included)
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 250V
Gender Male
Number of Rows 2
Number of Positions 7 (5 + 2 Coax or Power)
Connector Type Plug, Male Pins
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock, Grounding Indents, Mounting Brackets
Published 2010
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material, Finish Steel, Yellow Chromate Plated
Weight 11.969991g
Housing Material Polybutylene
Dielectric Material Polybutylene Terephthalate (PBT), Polyester
Number of Pins 7
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
