680-044-113R001
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB HD PLUG 44POS PNL MNT
PDF
/
Inventory: 5187
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Panel Mount, Through Hole
Insulation Material Glass
Shell Material Steel
Dielectric Material Polybutylene Terephthalate (PBT)
Housing Material PBT
Shell Material, Finish Steel, Nickel Plated
Technical
Operating Temperature -50°C~100°C
Packaging Tray
Published 2012
Series Seal-D 680
Feature Grounding Indents
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug, Male Pins
Number of Positions 44
Number of Rows 3
Gender Male
Contact Type Signal
Ingress Protection IP66 - Dust Tight, Water Resistant
Current Rating 5A
Contact Finish Gold
Voltage - Rated AC 500V
Flange Feature Housing/Shell (Unthreaded)
Plating Nickel
Connector Style D-Sub, High Density
Contact Form Stamped
Shell Size, Connector Layout 3 DB B High Density
Insulation Insulated
Dimensions
Contact Finish Thickness Flash
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Ratings Dust Tight, IP66, Water Resistant
