DCMMF37SNM
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 37POS PNL MNT
PDF
/
Inventory: 4006
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Dielectric Material Polycyclohexylenedimethylene Terephthalate (PCT)
Housing Material Thermoplastic
Body Material Brass
Shell Material, Finish Brass, Yellow Chromate Plated Cadmium
Technical
Operating Temperature -55°C~150°C
Packaging Bulk
Published 2000
Series 24308-Style, D*MM
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 37
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Receptacle
Contact Type Signal
Current Rating (Amps) 7.5A
Current Rating 7.5A
Contact Finish Gold
Number of Contacts 37
Wire Gauge 20-28 AWG
Flange Feature Housing/Shell (Unthreaded)
Connector Style D-Sub
Contact Form Machined
Shell Size, Connector Layout 4 DC C
Dimensions
Contact Finish Thickness 50.0μin 1.27μm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
