DB25P0L2A190
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Connector
PDF
/
Inventory: 4309
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mounting Type BOARD
Insulation Material THERMOPLASTIC
Shell Material STEEL
Mounting Style STRAIGHT
Mounting Option 2 LOCKING
Technical
Part Status Active
Number of Rows 2
Subcategory D Type Connectors
Contact Finish - Mating AU ON NI
Total Number of Contacts 25
Terminal Pitch 2.794mm
Shell Finish TIN
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 2.088 inch
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 125°C
Body Breadth 0.494 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.196 inch
Rated Current (Signal) 5A
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Body/Shell Style PLUG
Termination Type SOLDER
Dielectric Withstanding Voltage 1200VAC V
PCB Contact Row Spacing 2.54 mm
Contact Finish Termination TIN
Contact Pattern STAGGERED
Insulator Color BLACK
Dimensions
Length - Termination 0.205 inch
Compliance
RoHS Status Non-RoHS Compliant
