DAMMV7H2SN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
Conn Combo D-Subminiature SKT 5Power/2Signal POS Solder ST Thru-Hole 7 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $28.95
Unit Price: USD $28.952836
≥1 USD $28.952836
≥10 USD $27.314002
≥100 USD $25.76792
≥500 USD $24.30936
≥1000 USD $22.933354
Inventory: 8732
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 50.0μin 1.27μm
Technical
Shell Size, Connector Layout 2 DA A - 7W2
Contact Form Machined
Contact Current Rating 7.5A
Connector Style D-Sub, Combo
Flange Feature Board Side (4-40)
Contact Style Socket
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Total Number of Contacts 7
Current Rating (Amps) 7.5A 40A
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Signal and Power
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Gender Female
Number of Rows 2
Color Black
Number of Positions 7 (5 + 2 Power)
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Shielded
Series 24308-Style, Combo D?, D*MM
Published 2013
Packaging Bulk
Operating Temperature -55°C~150°C
Physical
Shell Material, Finish Steel, Yellow Chromate Plated Zinc
Dielectric Material Polycyclohexylenedimethylene Terephthalate (PCT)
Insulation Material POLYESTER
Number of Pins 7
Mounting Type Panel Mount, Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
