DEM9PLNMB

ITT Cannon
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description CONN D-SUB PLUG 9POS R/A SOLDER
PDF
/
Buying Options
Total Price: USD $99.69
Unit Price: USD $99.691684
≥1 USD $99.691684
≥10 USD $94.048756
≥100 USD $88.725241
≥500 USD $83.703059
≥1000 USD $78.965158
Inventory: 2690
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Length - Termination 0.158 inch

Technical

Insulator Color WHITE
Contact Pattern STAGGERED
Shell Size 1/E
Contact Resistance 55mOhm
Contact Style RND PIN-SKT
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern STAGGERED
Number of Contacts 9
Number Of PCB Rows 2
Shell Finish CHROMATE
Current Rating 7.5A
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
Gender Male
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type D-Sub, Plug, Signal
Termination Solder
Feature Shielded
Published 2015
Packaging Bulk

Physical

Housing Material Polyester
Shell Material STEEL
Mount Panel, Through Hole
Contact Plating Gold
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 12 Weeks
