DDM50SNMB
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 50POS PNL MNT
PDF
/
Buying Options
Total Price: USD $60.49
Unit Price: USD $60.493626
≥1 USD $60.493626
≥10 USD $57.069465
≥100 USD $53.839118
≥500 USD $50.79162
≥1000 USD $47.916618
Inventory: 6403
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Wire Size (Max) 20 AWG
Contact Design PREASSEM CONN
Insulator Color GREEN
Mating Contact Row Spacing 0.112 inch
Contact Pattern STAGGERED
Dielectric Withstanding Voltage 1700VAC V
Shell Size 5/D
Mating Contact Pitch 0.109 inch
Contact Resistance 55mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.186 inch
Empty Shell NO
Body Breadth 0.605 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 50
Reliability COMMERCIAL
Shell Finish CHROMATE
Current Rating 7.5A
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
Gender Female
Number of Rows 3
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type D-Sub, Receptacle, Signal
ECCN Code EAR99
Termination Solder
Feature Shielded
Published 2015
Packaging Bulk
Physical
Housing Material Thermoplastic
Shell Material BRASS
Mount Panel
Contact Plating Gold
Contact Material NOT SPECIFIED
