DCMM37SNMBK52
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 37POS PNL MNT
PDF
/
Inventory: 7111
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Plating Thickness 50μin
Technical
Contact Design PREASSEM CONN
Contact Rating (Current) 7.5A
Contact Pattern STAGGERED
Dielectric Withstanding Voltage 1700VAC V
Body/Shell Style PLUG
Mating Contact Pitch 0.109 inch
Contact Resistance 55mOhm
Contact Style Socket
Rated Current (Signal) 5A
Body Depth 0.186 inch
Body Breadth 0.494 inch
Number of Contacts 37
Shell Finish CADMIUM/YELLOW CHROMATE
Current Rating 7.5A
MIL Conformance YES
Contact Finish - Mating AU ON CU
Subcategory D Type Connectors
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Connector Type D-Sub, Receptacle, Signal
Termination Solder
JESD-609 Code e4
Published 2011
Packaging Bulk
Physical
Body Material Brass
Housing Material Polyester
Shell Material STEEL
Mount Panel
Contact Plating Gold
Contact Material COPPER ALLOY
