DBMME25PNMBK52
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Connector
PDF
/
Inventory: 9239
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Gold
Mount Panel
Shell Material STEEL
Housing Material Polyester
Body Material Brass
Technical
Packaging Bulk
Published 2011
Termination Solder
ECCN Code EAR99
Connector Type D-Sub, Plug, Signal
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Male
HTS Code 8536.69.40.30
Subcategory D Type Connectors
Contact Finish - Mating AU ON CU
MIL Conformance YES
Current Rating 7.5A
Shell Finish CADMIUM/YELLOW CHROMATE
Number of Contacts 25
Body Breadth 0.494 inch
Body Depth 0.196 inch
Rated Current (Signal) 5A
Contact Style Pin
Contact Resistance 55mOhm
Mating Contact Pitch 0.109 inch
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 1700VAC V
Contact Pattern STAGGERED
Contact Rating (Current) 7.5A
Contact Design PREASSEM CONN
Dimensions
Plating Thickness 50μin
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
