DBMME25PNMB

ITT Cannon
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub Connector
PDF
/
Inventory: 8215
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material COPPER ALLOY
Mounting Type PANEL
Insulation Material POLYESTER
Shell Material STEEL
Body Material Brass
Mounting Option 1 #4-40
Mounting Option 2 CLINCH NUT

Technical

Termination Solder
ECCN Code EAR99
Number of Rows 2
Gender Male
HTS Code 8536.69.40.30
Subcategory D Type Connectors
Contact Finish - Mating AU ON CU
MIL Conformance YES
Shell Finish CADMIUM/YELLOW CHROMATE
Reliability MIL-C-24308
Body Length or Diameter 2.088 inch
Number of Contacts 25
Operating Temperature (Max) 150°C
Body Breadth 0.494 inch
Operating Temperature (Min) -65°C
Body Depth 0.196 inch
Rated Current (Signal) 5A
Contact Style RND PIN-SKT
Contact Resistance 55mOhm
Mating Contact Pitch 0.109 inch
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 1700VAC V
Contact Pattern STAGGERED
Mating Contact Row Spacing 0.112 inch
Insulator Color GREEN
Contact Design PREASSEM CONN
Wire Size (Max) 20 AWG

Dimensions

Plating Thickness 50μin
Length - Termination 0.233 inch

Compliance

REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
