DAMAM15SNMB
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 15POS PNL MNT
PDF
/
Buying Options
Total Price: USD $84.12
Unit Price: USD $84.119937
≥1 USD $84.119937
≥10 USD $79.358438
≥100 USD $74.866443
≥500 USD $70.628727
≥1000 USD $66.630874
Inventory: 3285
Minimum: 1
-
+
Technical Details
Physical
Contact Material NOT SPECIFIED
Contact Plating Gold
Mount Panel
Shell Material STEEL
Housing Material Thermoplastic
Body Material Brass
Technical
Published 2013
Termination Crimp
Connector Type D-Sub, Receptacle, Signal
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Number of Rows 2
Gender Receptacle
Subcategory D Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Current Rating 7.5A
Shell Finish CHROMATE
Body Length or Diameter 1.541 inch
Number of Contacts 15
Body Breadth 0.494 inch
Empty Shell YES
Body Depth 0.186 inch
Rated Current (Signal) 5A
Contact Style RND PIN-SKT
Contact Resistance 55mOhm
Mating Contact Pitch 0.108 inch
Shell Size 2/A
Contact Pattern STAGGERED
Insulator Color GREEN
Contact Design PREASSEM CONN
Wire Size (Min) 30 AWG
Wire Size (Max) 18 AWG
Dimensions
Plating Thickness 50μin
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
