DAM15SNMBK52
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 15POS PNL MNT
PDF
/
Inventory: 2189
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Copper, Gold
Mount Panel
Housing Material Polyester
Body Material Brass
Technical
Published 2011
JESD-609 Code e4
Feature Shielded
Termination Solder
ECCN Code EAR99
Connector Type D-Sub, Receptacle, Signal
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Receptacle
HTS Code 8536.69.40.30
Subcategory D Type Connectors
Contact Finish - Mating GOLD (50) OVER COPPER (100)
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Orientation Straight
Current Rating 7.5A
Reliability COMMERCIAL
Number of Contacts 15
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.494 inch
Empty Shell NO
Body Depth 0.186 inch
Rated Current (Signal) 5A
Contact Style Socket
Contact Resistance 55mOhm
Mating Contact Pitch 0.109 inch
Shell Size 2/A
Dielectric Withstanding Voltage 1700VAC V
Contact Pattern STAGGERED
Contact Rating (Current) 7.5A
Contact Design PREASSEM CONN
Dimensions
Length 39.14mm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
