09694117214
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Mixed Contact Connectors DSUB ML 21WA4 WITH SLDRCUP PL3
PDF
/
Buying Options
Total Price: USD $8.11
Unit Price: USD $8.1136
≥1 USD $8.1136
≥10 USD $7.304
≥100 USD $6.880544
≥500 USD $6.704192
≥1000 USD $6.527752
≥3000 USD $5.82208
Inventory: 128
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 12.5mm
Length 69.3mm
Technical
Shell Size, Connector Layout 4 DC C - 21WA4
Connector Style D-Sub, Combo
Flange Feature Housing/Shell (Unthreaded)
Wire Gauge 20 AWG
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Depth 14.3mm
Orientation Straight
Total Number of Contacts 21
Current Rating (Amps) 5A
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Signal and Coax or Power (Not Included)
Filter Feature NO
IEC Conformance NO
DIN Conformance YES
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Gender Male
Number of Rows 2
Color Green
Number of Positions 21 (17 + 4 Coax or Power)
Connector Type Plug, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Grounding Indents
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material, Finish Steel, Tin Plated
Housing Material Glass
Dielectric Material Polyester Thermoplastic, Glass Filled
Mounting Type Free Hanging (In-Line)
Mount Free Hanging, Panel
Contact Plating Gold
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 9 Weeks
