09651616712

HARTING
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description CONN D-SUB PLUG 9POS VERT SOLDER
PDF
/
Buying Options
Total Price: USD $3.84
Unit Price: USD $3.8368
≥1 USD $3.8368
≥10 USD $3.47952
≥100 USD $3.296128
≥500 USD $3.066008
≥1000 USD $2.682768
≥3000 USD $2.60612
Inventory: 909
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Length 31.5mm
Height 12.5mm

Technical

Test Voltage 1kV
Shell Size, Connector Layout 1 DE E
Contact Form Stamped
Body Plating Tin
Number of Ports 1
Connector Style D-Sub
Flange Feature Housing/Shell (4-40)
Working Voltage 250V
Empty Shell NO
Current Rating 7.5A
Depth 12.5mm
Orientation Straight
Total Number of Contacts 9
Pitch 2.74mm
Current Rating (Amps) 6.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Signal
Filter Feature NO
IEC Conformance YES
DIN Conformance YES
MIL Conformance NO
Voltage - Rated DC 250V
Gender Male
Number of Rows 2
Connector Type Plug, Male Pins
Termination Solder
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock, Grounding Indents
Packaging Tray
Operating Temperature -55°C~125°C

Physical

Shell Material, Finish Steel
Body Material Metal
Housing Material Polybutylene
Dielectric Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Shell Material PBT
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 4 Weeks
