09643247243
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Board Lock Filter Grounding Indents Gold Plug, Male Pins Connector -20C~125C 7.5A 100V
PDF
/
Inventory: 8584
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Material Flammability Rating UL94 V-0
Technical
Shell Size, Connector Layout 3 DB B
Contact Form Machined
Connector Style D-Sub
Flange Feature Housing/Shell (M3)
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Reach Compliance Code compliant
Total Number of Contacts 25
Current Rating (Amps) 7.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Signal
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature PANEL MOUNTABLE
Voltage - Rated 100V
Number of Rows 2
Number of Positions 25
Connector Type Plug, Male Pins
Termination Solder
Part Status Active
Feature Board Lock, Filter, Grounding Indents
Packaging Bulk
Operating Temperature -20°C~125°C
Physical
Shell Material, Finish Steel
Dielectric Material Polycyclohexylenedimethylene Terephthalate (PCT)
Insulation Material GLASS FILLED PCT
Mounting Type Through Hole, Right Angle
Contact Material Copper Alloy
